AMD 100-100001084WOF AMD Ryzen 7 9800X3D 8Cores/16Threads 4.7GHz Desktop Processor
$688.87
Was: $826.64
Availability:
In Stock
Richmond BC Warehouse:
0
Toronto ON Warehouse:
4
Product Code:
15077
Brand:
AMD
Mfg Sku:
100-100001084WOF
Share to:
Specification
AMD 100-100001084WOF AMD Ryzen 7 9800X3D 8Cores/16Threads 4.7GHz Desktop Processor
| UPC: | 730143315289 |
Detail Specifications
| General Specifications Name AMD Ryzen 7 9800X3D Family Ryzen Series Ryzen 9000 Series Form Factor Desktops , Boxed Processor Market Segment Enthusiast Desktop Regional Availability Global Former Codename Granite Ridge AM5 Processor Architecture Zen 5 Number of CPU Cores 8 Multithreading (SMT) Yes Number of Threads 16 Max. Boost Clock Up to 5.2 GHz Base Clock 4.7 GHz L1 Cache 640 KB L2 Cache 8 MB L3 Cache 96 MB Default TDP 120W Processor Technology for CPU Cores TSMC 4nm FinFET Processor Technology for I/O Die TSMC 6nm FinFET Package Die Count 2 Unlocked for Overclocking Yes AMD EXPO Memory Overclocking Technology Yes Precision Boost Overdrive Yes Curve Optimizer Voltage Offsets Yes AMD Ryzen Master Support Yes CPU Socket AM5 Supporting Chipsets A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 Thermal Solution (PIB) Not Included Recommended Cooler Liquid cooler recommended for optimal performance Max. Operating Temperature (Tjmax) 95oC Launch Date 11/07/2024 OS Support Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Connectivity Native USB 3.2 Gen 2 (10Gbps) 4 Native USB 2.0 (480Mbps) 1 PCI Express Version PCIe 5.0 Native PCIe Lanes (Total/Usable) 28 , 24 NVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10 System Memory Type DDR5 Memory Channels 2 Max. Memory 256 GB System Memory Subtype UDIMM Max Memory Speed 2x1R DDR5-5600 2x2R DDR5-5600 4x1R DDR5-3600 4x2R DDR5-3600 ECC Support Yes (Requires mobo support) |
| Graphics Capabilities Graphics Model AMD Radeon Graphics Graphics Core Count 2 Graphics Frequency 2200 MHz USB Type-C DisplayPort Alternate Mode Yes |
| Key Features Supported Technologies AMD EXPO Technology , AMD Ryzen Technologies |
| Item Dimension (L"xW"xH") 6 x 4 x 6 Weight 2 lbs Warranty Information 3 years (Manufacture) |
