Synology DS218 NAS 2 Bay 64 Bit 2GB DDR4 RAM USB 3.0 / RJ45 DiskStation (Diskless) Network Attached Storage

$359.87
Was: $431.84
Availability:
In Stock
Richmond BC Warehouse:
Toronto ON Warehouse:
Product Code:
14624
Brand:
Synology
Mfg Sku:
DS218


Share to:

Specification

Synology DS218 NAS 2 Bay 64 Bit 2GB DDR4 RAM DiskStation (Diskless) Network Attached Storage



UPC: 846504002962

Detail Specifications
  CPU
CPU Model: Realtek RTD1296
CPU Architecture: 64-bit
CPU Frequency: Quad Core 1.4 GHz
Hardware Encryption Engine: Yes
Hardware Transcoding Engine: 10-bit H.265 (HEVC), MPEG-4 Part 2, MPEG-2, VC-1, maximum resolution: 4K (4096 x 2160), maximum frame rate per second (FPS): 60
  Memory
Drive Bays: 2
Compatible Drive Type:
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
Maximum Internal Raw Capacity: 24 TB (12 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size: 108 TB
Hot Swappable Drive: Yes
  External Ports
RJ-45 1GbE LAN Port: 1
USB 2.0 Port: 1
USB 3.0 Port: 2
Copy Button: Yes
  File System
Internal Drives: EXT4
External Drives:
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
- exFAT
  Others
System Fan: 92 mm x 92 mm x 1 pcs
Fan Speed Mode:
- Full-Speed Mode
- Cool Mode
- Quiet Mode
Brightness adjustable front LED indicators : Yes
Power Recovery: Yes
Noise Level: 19.3 dB(A)
Scheduled Power On/Off: Yes
Wake on LAN/WAN: Yes
Power Supply Unit / Adapter: 60W
AC Input Power Voltage: 100V to 240V AC
Power Frequency: 50/60 Hz, Single Phase
Power Consumption:
- 14.99 W (Access)
- 5.78 W (HDD Hibernation)
British Thermal Unit:
- 51.15 BTU/hr (Access)
- 19.72 BTU/hr (HDD Hibernation)
  Environment Temperature
Operating Temperature: 0oC to 40oC (32oF to 104oF)
Storage Temperature: -20oC to 60oC (-5oF to 140oF)
Relative Humidity: 5% to 95% RH
  Certification
- FCC Class B
- CE Class B
- BSMI Class B
- EAC
- CCC
- RCM
- KC
  Storage Management
Maximum Internal Volume Number: 256
Maximum iSCSI Target Number: 10
Maximum iSCSI LUN: 10
SSD TRIM: Yes
Supported RAID Type:
- Synology Hybrid RAID
- Basic
- JBOD
- RAID 0
- RAID 1
RAID Migration: Basic to RAID 1
Volume Expansion with Larger HDDs:
- Synology Hybrid RAID
- RAID 1
Volume Expansion by Adding a HDD: Synology Hybrid RAID
  Add-on Packages
Chat: Yes
Maximum Users: 500
  Cloud Station Server
Maximum Number of Concurrently Connected Devices: 200
Maximum Number of Synced Files (ext4): 100,000 / single file reaction time 632 ms
Notes:
- The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time. For more information on file processing capability, please refer to the reaction time for file processing.
- File reaction time refers to the preparation time required for other devices to start downloading a 10KByte file from a Synology NAS after the file has been added to the NAS. RAM expansion was not used during testing.
- Non-encrypted shared folders were used during the aforementioned testing. Download Station
Maximum Concurrent Download Tasks: 30 Drive
Maximum Number of Synced Files: 100,000 / single file reaction time 941 ms
Maximum Number of Concurrent Connections for PC Clients: 200
Notes:
- The EXT4 file system was used for the purpose of testing.
- The maximum number of concurrent connections refers to the maximum number of connections that could be maintained when the maximum number of synced files was reached.
- File reaction time refers to the preparation time required for other devices to start downloading a 10KByte file from a Synology NAS after the file has been added to the NAS.
- Non-encrypted shared folders were used during the aforementioned testing.
  exFAT Access (optional)
Yes
  Media Server
DLNA Compliance: Yes
  Moments
Facial recognition: Yes
Subject recognition: Yes
  Office
Maximum Users: 200
Notes:
- Multiple files were opened for testing and each file was edited by 30 users simultaneously.
- CPU and RAM usage were both under 80% when the number of maximum users was reached.
- Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
  Surveillance Station
Maximum IP cam (Licenses required): 20 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264):
- 600 FPS at 720p (1280x720)
- 300 FPS at 1080p (1920 x 1080)
- 200 FPS at 3M (2048x1536)
- 150 FPS at 5M (2591x1944)
- 110 FPS at 4K (3840x2160)
Total FPS (H.265):
- 600 FPS at 720p (1280x720)
- 300 FPS at 1080p (1920 x 1080)
- 240 FPS at 3M (2048x1536)
- 200 FPS at 5M (2591x1944)
- 180 FPS at 4K (3840x2160)
Total FPS (MJPEG):
- 240 FPS at 720p (1280x720)
- 200 FPS at 1080p (1920 x 1080)
- 130 FPS at 3M (2048x1536)
- 80 FPS at 5M (2591x1944)
Notes: Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
  Video Station
Video Transcoding: 4K Group 3 (See more)
Maximum Transcoding Channel Number:
- 1 channel, 60 FPS at 4K (4096 x 2160), H.265 (HEVC), 10-bit or
- 1 channel, 30 FPS at 1080p (1920 x 1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1
VPN Server: Yes
Maximum Connections: 5
  Environment and Packaging
Environment: RoHS Compliant
Packaging Content:
- Main Unit X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 1
- Quick Installation Guide X 1
Optional Accessories:
- Surveillance Device License Pack
- VS360HD
- VS960HD
  Item Dimension ( L inchxW inchxH inch)
11 x 10 x 5
  Weight
5.41 lb
  Warranty Information
2 Years Manufacture Warranty
